About this item

Easy to use: Connects via USB, serial, or ethernet and is compatible with thermal transfer rolls with a 3 in core and 8 in diameter
Use with thermal ribbon: Prints using thermal transfer technology which uses a wax/resin ribbon instead of expensive ink or toner
Enterprise grade quality: Sturdy, simple and smart, the ZT411 is ideal for manufacturing, transportation, healthcare and retail
Save time and money: Prints 14 in/sec at 300 dpi, energy star approved, and on demand printing allows you to print exact quantities instead of wasting 8.5 x 11 sheets of labels
Sturdy construction: Equipped with a metal frame and a bi-fold metal media cover with an enlarged clear viewing window

Standard Features

Print Methods: Thermal transfer and direct thermal printing
Construction: Metal frame and bi-fold metal media cover with enlarged clear
viewing window
Side-loading supplies path for simplified media and ribbon loading
Thin film printhead with E3™ Element Energy™ Equalizer for superior print quality
Communications: USB 2.0, high-speed, RS-232 Serial, 10/100 Ethernet,
Bluetooth 4.1, Dual USB Host
4.3-inch color touch display with intuitive menu for quick operation and settings
management
Bi-colored status LEDs for quick printer status
ENERGY STAR qualified
Zebra Designer Essentials: easy label design tool free at

Physical Characteristics

Dimensions (closed)*	ZT411: 19.5 in. L x 10.6 in. W x 12.75 in. H 495 mm L x 269 mm W x 324 mm H ZT421: 19.5 in. L x 13.25 in. W x 12.75 H 495 mm L x 336 mm W x 324 mm H Dimensions are for the base model printer. Consult your sales representative for specifics regarding other configurations.
Weight	ZT411: 36 lbs./16.33 kg ZT421: 40 lbs./18.14 kg

Printer Specifications

Resolution	203 dpi/8 dots per mm 300 dpi/12 dots per mm (optional) 600 dpi/24 dots per mm (optional for ZT411 only)
Memory	256 MB SDRAM memory 512 MB on-board linear Flash memory
Maximum Print Width	ZT411: 4.09 in./104 mm ZT421: 6.6 in./168 mm
Maximum Print Speed	ZT411: 14 ips/356 mm per second ZT421: 12 ips/305 mm per second
Media Sensors	Adjustable dual media sensors: transmissive and reflective
Print Length	ZT411 203 dpi: 157 in./3988 mm 300 dpi: 73 in./1854 mm 600 dpi: 39 in./991 mm ZT421 203 dpi: 102 in./2591 mm 300 dpi: 45 in./1143 mm

Media Characteristics

Maximum Media Width	ZT411 1.00 in./25.4 mm to 4.5 in./114 mm tear/cutter 1.00 in./25.4 mm to 4.25 in./108 mm peel/rewind ZT421 2.00 in./51 mm to 7.0 in./178 mm tear/cutter 2.00 in./51 mm to 6.75 in./171 mm peel/rewind
Maximum Media Roll Size	8.0 in./203 mm O.D. on a 3 in./76 mm I.D. core
Thickness	0.0023 in./0.058 mm to 0.010 in./0.25 mm
Media Types	Continuous, die-cut, notch, black-mark

Ribbon Characteristics

Environmental

Operating Temperature	Thermal transfer: 40º F to 104º F/5º C to 40º C Direct thermal: 32º F to 104º F/0º C to 40º C
Storage/Transportation Temperature	-40º F to 140º F/-40º C to 60º C
Operating Humidity	20% to 85% non-condensing
Storage Humidity	5% to 85% non-condensing
